Specification
Internet Connection |
Supported WAN type |
Static IP, Dynamic IP, PPPoE, PPPoA |
Connection Scheme |
Connect-on-demand, Auto-Disconnect |
|
NAT Function |
One-to-Many NAT |
Class C One-to-Many; Max 253 User |
Virtual Server |
Yes |
|
DMZ Host |
One DMZ Host |
|
Access Control |
URL blocking |
Domain Access Control |
Packet Filtering |
Inbound/Outbound IP Filter, MAC Access Control |
|
Firewall |
Firewall |
NAT Firewall |
Hacker attack logging |
View by web-based |
|
VPN |
Pass Through |
PPTP, L2TP and IPSec |
Routing |
Static Route, Dynamic Route (RIP1/2) |
|
User Authentication |
Password protected browser-based UI |
|
Event Logging |
Syslog supported, On-web logging, Email Alert |
|
Configuration Management |
Web based and SNMP |
|
Upgrade method |
FTP or Web based Window AP |
|
Physical Dimension |
||
Chassis (W x D x L) |
164mm*122mm*29mm |
|
PCBA (W x D x L) |
138mm*101.7mm*18mm |
|
LED Indication |
Power, Act, Link, USB, 4*LAN, WLAN |
|
Environment, Certification, Reliability |
||
Operating |
Temperature: 0~40 ℃ , Humidity 10%~90% non-condensing |
|
Storage |
Temperature: -20~70 ℃ , Humidity: 0~95% non-condensing |
|
EMC/Safety |
FCC, CE, |
|
Reliability |
Stress test; Vibration test; Drop Testing |
|
|
|
|
