| Applications |
Video-On-Demand |
|
Telecommuting |
|
Distance learning |
|
E-Commerce |
|
Online gaming |
|
Video conferencing |
| ADSL Compliant |
ANSI T1.413 issue 2 |
|
ITU-T G.992.1 (G.dmt) |
|
ITU-T G.992.2 (G.lite) |
| G.994.1 (G.hs, Multimode) |
| ITU-T G.992.3 (ADSL2 G.dmt.bis) |
| ITU-T G.992.4 (ADSL2 G.lite.bis) |
|
ITU-T G.992.5 (ADSL2+; Annex A, B, I, J, L & M) |
|
Reach Extended ADSL (RE ADSL) |
| ATM and PPP Protocols |
ATM Forum UNI 3.1/4.0 PVC |
|
Support up to 8PVCs |
|
Traffic Shaping (ATM QoS) UBR, CBR, VBR |
|
Multi Protocol over AAL5 (RFC1483 / 2684) |
|
OAM F4 and F5 segment end-to-end loopback, AIS, and RDI OAM cells |
|
VC and LLC Multiplexing |
|
VPI is 0-255 and VCI is 32-65535 |
|
PPP over Ethernet (RFC 2516) |
|
PPP over ATM (RFC 2364) |
| Bridging / Routing |
Ethernet to ADSL self-learning Transparent Bridging (IEEE 802.1D) |
|
IP routing-RIPv2 (backward compatible with RIPv1) |
|
Static IP routing |
|
Routing (TCP/IP/UDP/ARP/ICMP) |
|
IP Multicast IGMP v1/v2 |
| IP Management |
NAT (Network Address Translation) |
|
NAPT (Network Address and Port Translation) |
|
Virtual Server (IP forwarding) and DMZ host |
|
DHCP Server / Relay / Client (WAN Port) |
|
VPN (IPSec, PPTP, L2TP) Pass-Through |
|
DNS Proxy |
|
Dynamic DNS |
|
UPnP support |
| Wireless |
IEEE802.11g compliance, backward compatible with 802.11b (at 11Mbps) |
|
64/128 bits WEP Encryption |
|
WPA, WPA-TKIP/PSK |
|
MAC Address Filtering |
| Security |
PPP over PAP (Password Authentication Protocol; RFC1334) |
|
PPP over CHAP (Challenge Authentication Protocol; RFC1994) |
|
Built-in NAT Firewall |
|
IP-based Packet filtering |
|
Password Protected System Management |
| HTTP Web-based management |
Web-based GUI Configuration / Management |
|
Command-line Interpreter (CLI) |
|
Telnet Remote Management |
|
Firmware upgrade via FTP / TFTP |
|
SNMP Support (V.1 and V.2C) |
|
Built-in Diagnostic tool for ADSL and IP Ping |
| Interface |
Four RJ45 ports compatible with IEEE 802.3/802.3u, 10/100Mbps auto selection |
|
One RJ11 port for ADSL connection |
|
One power switch button |
|
One reset button for restoration of factory default setting |
| Support OS |
Windows 98SE, ME, 2000, XP, Mac OS X |
| Power Requirement |
Power Adapter: Input 110 |
|
±10 or 230 |
|
±10 VAC, Output 12VAC 1000mA |
| Environmental |
Operating temperature: 0 ° C ~ 70 ° C ambient |
|
Humidity: 5 % ~ 95 % (non-condensing) |
|
Storage temperature: -40 ° C ~ 70 ° C |
