Specification:
Standard |
IEEE 802.11g and 802.11b |
Host Interface |
USB 2.0 |
USB Connector Type |
A-type USB2.0 connector |
Antenna Connector |
Chip antenna |
Frequency Range |
2.412GHz ~ 2.4835GHz |
Operating Frequency / Channel |
2.412~2.462GHz (FCC, Canada ) / 11 Channels 2.412~2.4835GHz ( Japan , TELEC) / 14 Channels 2.412~2.472GHz (Euro ETSI) / 13 Channels |
Modulation Technique |
Orthogonal frequency division multiplexing (OFDM) |
Security |
64/128bit WEP |
Media Access Protocol |
CSMA/CA (Collision Avoidance) with ACK |
Output power |
11g: 14dBm (Typical) 11b: 17dBm (Typical) |
Data Rate |
802.11g - 54, 48, 36, 24, 18, 12, 9 and 6Mbps with auto-rate fall back |
Sensitivity |
54Mbps: -68dBm 11Mbps: -80dBm |
Working Mode |
Ad-Hoc, Infrastructure |
Operation Voltage |
3.3 Volts |
Power Consumption |
Continuous transmission mode: 290mA at 5VDC (Ave.) Continuous Reception mode: 240mA at 5VDC (Ave.) |
Operation Temperature |
-10~+60 °C |
Humidity |
5~90 % (Non Condensing) |
Regulatory Approval |
FCC, CE |
Dimensions |
71.5mm (L) × 19mm (W) × 7.9mm (H) |
LED Indicator |
Link/ACTIVE: Orange |
OS Support |
Win98/SE/ME, Win2000, WinXP, WinCE, Linux, MAC OSX |
Throughput |
20.5Mbps@ 54Mbps 5.7Mbps@ 11Mbps |
